OD:1-40, 40-60mm
Item | SIZE (mm) | O.D. TOLERANCES | OVALITY | BOW |
GR01 | 1.0 | ± .20mm | .10mm | 1.3mm / 1200mm long |
GR01.5 | 1.5 | ± .30mm | .12mm | 1.3mm / 1200mm long |
GR2 | 2.0 | ± .20mm | .15mm | 1.3mm / 1200mm long |
GR2.5 | 2.5 | ± .25mm | .10mm | 1.3mm / 1200mm long |
GR3 | 3.0 | ± .30mm | .10mm | 1.3mm / 1200mm long |
GR4 | 4.0 | ± .15mm | .10mm | 1.3mm / 1200mm long |
GR5 | 5.0 | ± .15mm | .10mm | 1.3mm /1200mm long |
GR6 | 6.0 | ± .15mm | .10mm | 1.3mm / 1200mm long |
GR6.4 | 6.4 | ± .20mm | .10mm | 1.3mm / 1200mm long |
GR7 | 7.0 | ± .30mm | .10mm | 1.3mm / 1200mm long |
GR8 | 8.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm long |
GR9 | 9.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm long |
GR10 | 10.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm long |
GR11 | 11.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm mm long |
GR12 | 12.0 | ± 1.5% | 1% maximum | 1.3mm /1200mm mm long |
GR13 | 13.0 | ± 1.5% | 1% maximum | 1.3mm /1200mm mm long |
GR14 | 14.0 | ± 1.5% | 1% maximum | 1.3mm /1200mm mm long |
GR15 | 15.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm mm long |
GR16 | 16.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm mm long |
GR17 | 17.0 | ± 1.5% | 1% maximum | 1.3mm /1200mm mm long |
GR18 | 18.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm mm long |
GR19 | 19.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm mm long |
GR20 | 20.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm mm long |
GR22 | 22.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm mm long |
GR25 | 25.0 | ± 1.5% | 1% maximum | 1.3mm / 1200mm mm long |
GR26 | 26.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR27 | 27.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR28 | 28.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR29 | 29.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR30 | 30.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR31 | 31.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR32 | 32.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR33 | 33.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR34 | 34.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR35 | 35.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR36 | 36.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR37 | 37.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR38 | 38.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
GR40+ | 40.0 | ± 1.5% | 1% maximum | 1.3mm / 1220mm long |
